Stainless steel 2205

1.4462 | X2CrNiMoN22-5-3

ProcessCNC Machining

Need this material for your project?

Upload your drawing and get manufacturing support from our engineering team.

* Property values are for reference and may vary by alloy, temper, and processing conditions.

Stainless steel 2205 is a duplex stainless steel combining austenitic and ferritic structures, offering excellent strength, corrosion resistance, and fatigue performance. It provides higher strength than 304 and better corrosion resistance than 316, making it suitable for high-load, stress-corrosion-resistant, and complex structural components.

Material Properties

Mechanical Properties

Yield strength
450 - 510 MPa (Annealed)
Tensile strength
620 - 750 MPa (Annealed)
Elongation
25 - 30 %
Hardness
230 - 270 HB
Young's modulus
190 - 200 GPa

Thermal properties

Maximum operating temperature
280 - 325 °C
Thermal conductivity
15 - 20 W/(m·K)
Coefficient of thermal expansion
10.4 - 13.7 μm/(m·℃)

Physical Properties

Density
7.80 g/cm³

Electrical properties

Electrical resistivity
80 - 90 μΩ·cm

Manufacturability

Manufacturability-Corrosion resistance
Good
Manufacturability-Weldability
Good
